AP6W - Alta Labs 4-Stream Wall Mount Enterprise WiFi 6 Access Point
Description
Description
The Alta Labs AP6W is a 4-stream wall mount enterprise WiFi 6 access point designed for seamless integration into hospitality environments, multi-dwelling units, corporate offices, and residential spaces. With its compact, sleek aesthetic design and versatile mounting options, the AP6W delivers optimal dual-band WiFi 6 performance across 2.4 GHz (2x2 MIMO) and 5 GHz (2x2 MIMO) bands, providing up to 3.0 Gbps of combined wireless throughput.
Built on Qualcomm's Dragonwing N6 platform, the AP6W features advanced MU-MIMO technology for simultaneous multi-device connectivity and supports the latest WiFi 6 (802.11ax) standard. The access point includes three Gigabit Ethernet RJ45 ports with flexible powering options—PoE+ input (42.5-57V, 0.6A) via either the rear or bottom port, plus a PoE passthrough port on the bottom for daisy-chaining additional devices. Alternatively, it can be powered using a 12VDC, 1.5A power supply (sold separately).
Ideal for: Hotels, restaurants, resorts, entertainment venues, multi-dwelling units (MDUs), corporate offices, and residential installations requiring professional-grade WiFi with elegant aesthetics and easy wall or junction box mounting.
Key Features
- WiFi 6 (802.11ax) dual-band wireless: 2x2 MIMO on 2.4 GHz and 5 GHz, up to 3.0 Gbps total throughput
- Three Gigabit Ethernet ports with PoE+ input and PoE passthrough capability
- AltaPass™ multi-password technology—patented feature allowing multiple passwords on a single SSID with customisable network/internet settings per password
- Advanced DPI content filtering engine for powerful network insights, security controls, and website/app blocking
- Hotspot functionality with customisable branded login pages, terms of service, and landing pages
- Bluetooth setup for seamless configuration via the Alta Networks mobile app
- Cloud-based or self-hosted management via intuitive Alta Control™ interface with real-time monitoring
- Port-based VLANs and traffic statistics for enhanced network segmentation
- Seamless roaming and advanced traffic management
- Compact dimensions: 156.1 x 90 x 43.9 mm (6.15 x 3.54 x 1.73"), weight 0.312 kg (0.68 lbs)
- Wall mount or junction box mount with included mounting hardware
- Indoor use, operating temperature 0 to 40°C (32 to 104°F)
- Polycarbonate top cover with aluminium bottom cover for durability
Compatible Products
Alta Labs PoE+ Switches: The AP6W pairs perfectly with Alta Labs managed PoE+ switches including the S8-PoE (8-port compact switch with 60W PoE budget), S16-PoE (16-port rack-mountable switch with 120W PoE budget), S24-PoE (24-port switch with 240W PoE budget and SFP+ uplinks), and S48-APOE (48-port high-performance switch with 740W PoE budget). All Alta Labs switches support 802.3at PoE+ and 802.3af PoE standards, feature cloud-based management, and include Bluetooth setup for seamless integration.
Alta Labs Access Points: Deploy the AP6W alongside other Alta Labs WiFi 6 access points such as the AP6 (ceiling mount), AP6-Pro (ceiling mount with 4x4 MIMO and 6.3 Gbps throughput), and AP7-Pro (outdoor-rated WiFi 6 AP) to create a unified, scalable wireless network managed through a single cloud interface.
Alta Labs Route10: The Route10 multi-WAN router with 10 Gbps SFP+ ports and hardware-accelerated VPN provides enterprise-grade routing performance to complement your AP6W deployment, with load balancing, real-time statistics, and centralised management.
-
About Alta Labs
Futureproof and optimise your entire network with Alta Labs, an innovative provider of integrated wireless and networking solutions. Leveraging proprietary software and next-generation hardware technology, Alta Labs streamlines your network hardware configuration and simplifies installation to deliver a suite of customisable and interoperable solutions - all at a decent price point!
Alta Labs pairs seamless functionality with exceptional performance. Their full complement of access points, networking switches, routers and controllers enables you to effortlessly build your home or office network, whilst tailoring the implementation to your specific network system design.
Alta Labs has curated a selection of highly configurable switches designed to elevate connectivity in your home or business. Available in a range of different speeds and port configurations, they are offered with flexible mounting options and Bluetooth for seamless device setup.
For corner-to-corner Gigabit class connectivity, look for an Alta Labs Access Point. Each option in their range delivers high-performance WiFi 6 and PoE-powered functionality to facilitate seamless roaming throughout your network.
The innovative, high-performance Alta Labs Router is designed to complete their product ecosystem. It offers maximum performance at a minimal retail price point.
Each element of the network can be managed through one of the Alta Labs centralised management options - cloud-based management through their Alta Cloud Management Platform, SaaS software for self-hosting, or Control, their hardware-based local controller.
Powered by SoundVision Technologies, a global audio and electrics manufacturer, and partnering with trusted networking brands such as TruAudio and VSSL, the industry-leading team of professionals at Alta Labs have extensive experience in the network technology development space.
-
