SKU: Omada NVR16-8P-2T(UN)

Omada NVR16-8P-2T(UN) - TP-Link Omada 16-Channel Network Video Recorder with 8-Port PoE+ and 2TB HDD

$701.05 AUD
Add to cart, then request a quote for our best price.

Description

The TP-Link Omada NVR16-8P-2T(UN) is a professional 16-channel network video recorder designed to deliver powerful surveillance management within the Omada ecosystem. Pre-installed with a 2TB hard drive, this PoE+ NVR offers comprehensive video storage and playback capabilities for small to medium-sized business security installations.

Key Features

  • 16-Channel Live View – Monitor up to 16 camera feeds simultaneously for complete site coverage
  • 8× PoE+ Ports – Power and connect up to 8 IP cameras with Power over Ethernet, simplifying installation
  • Pre-installed 2TB HDD – Ready-to-use storage for continuous recording straight out of the box
  • 4K HDMI Video Output – Crystal-clear video playback on external displays for detailed monitoring
  • 16-Channel Synchronous Playback – Review footage from multiple cameras simultaneously for efficient incident investigation
  • Expandable Storage – 1 SATA interface supporting HDDs up to 16TB for extended recording capacity
  • Multiple Management Options – Configure via GUI, web interface, or Omada Guard App for flexible deployment
  • Omada Cloud Service Compatible – Enable remote access and management through TP-Link's cloud platform
  • ONVIF Support – Integrate Omada cameras or third-party ONVIF-compatible cameras for versatile surveillance solutions

The Omada NVR16-8P-2T functions as a storage management device that seamlessly integrates with Omada cameras and third-party IP cameras, storing video footage reliably on its internal hard drive. The built-in PoE+ capability eliminates the need for separate power supplies for connected cameras, reducing installation complexity and costs.

Administrators can initialise and manage the NVR through three convenient methods: the intuitive graphical user interface (GUI) via HDMI or VGA connection, the comprehensive web management interface accessible from any network-connected PC, or the mobile Omada Guard App for on-the-go configuration and monitoring.

Ideal for: Retail stores, offices, warehouses, educational institutions, and small business premises requiring reliable, professional-grade video surveillance with centralised storage and PoE camera connectivity.

Compatible Products

Omada IP Cameras
The NVR works seamlessly with TP-Link's Omada range of IP cameras, including 12MP, 8MP, 5MP Turret and Bullet models, providing plug-and-play integration within the Omada ecosystem.

Third-Party ONVIF Cameras
Supports ONVIF Profile S/G/T, allowing integration with third-party IP cameras from various manufacturers that comply with ONVIF standards.

Surveillance-Grade Hard Drives
Compatible with 3.5-inch SATA surveillance HDDs up to 16TB capacity. Recommended drives include Western Digital Purple and Seagate SkyHawk series, designed for continuous 24/7 recording.

Omada Guard App
Mobile management application for iOS and Android devices, enabling remote configuration, live viewing, and playback from anywhere with internet connectivity.

Frequently asked questions5 questions
How many cameras can this NVR manage, and can it power them?
It has 16 channels and 8 PoE+ ports (802.3at/af) that power and connect IP cameras over a single cable. The PoE budget is 115 W in total, with up to 30 W per port.
Is a hard drive included, and can I add more storage?
Yes, a 2TB HDD comes pre-installed and is ready to record. There is one SATA interface supporting drives up to 16TB, and surveillance-grade 3.5-inch SATA HDDs are recommended for 24/7 recording.
Does it work with third-party cameras?
Yes. It supports ONVIF Profile S/G/T, so compatible third-party IP cameras can be integrated alongside Omada cameras, which offer plug-and-play integration.
How many high-resolution cameras can it handle?
It manages 16 cameras at HD or 2K/5MP, 12 at 4K/8MP, 8 at 12MP and 6 at 16MP. Playback is 16-channel synchronous.
How do I set up and view footage on the NVR?
You can configure it through the on-screen GUI via HDMI or VGA, the web interface, or the Omada Guard App on iOS and Android. HDMI output supports up to 3840x2160 at 30Hz, and HDMI and VGA can output simultaneously.

Click HERE to access the Datasheet

Click HERE to access the Installation Guide
