The WatchAI 4 Port Unmanaged PoE Switch (SKU: SWUM-5P-GB-POE) is a plug-and-play PoE switch designed to power and connect IP cameras and access-control devices. With four IEEE 802.3af/at PoE ports and two uplink ports, it delivers both power and data over a single Ethernet cable, simplifying installation and reducing cabling requirements.

A built-in Extender/CCTV mode enables long-distance transmission, making the SWUM-5P-GB-POE a simple, reliable choice for surveillance deployments. It is NDAA compliant, RCM certified, and suits both desktop and wall-mount installation.

Key Features

• 4 × PoE ports (10/100Base-T, IEEE 802.3af/at) supplying data and power, up to 30W per port
• 2 × uplink RJ45 ports (10/100Base-T) for connecting to a router, NVR or existing network
• 65W total power (AC 100–240V), with an average of 15.4W per port
• Extender + CCTV mode function switch for long-distance transmission (reboot to apply)
• 1.6 Gbps non-blocking switching capacity with store-and-forward, full wire-speed operation
• Packet forwarding rate of 0.89 Mpps at 64 bytes, 1K-entry MAC address table and 768K buffer
• Auto-detect, full/half duplex and MDI/MDI-X auto-sensing for hassle-free setup
• Low standby power (under 3W); full load under 65W
• Compact 142 × 114.5 × 40mm body, weighing less than 0.6kg
• Desktop and wall-mount installation

Ideal for: installers, security integrators and small businesses building CCTV and IP camera systems, access-control deployments, and commercial networks that need a straightforward, unmanaged PoE solution.

Compatible Products

Works with PoE-powered WatchAI devices, including the WatchAI Panoramic Turret 180° 8MP camera (PoE 802.3af), the Intelligent 8MP AI security camera, and the Intelligent 4MP ANPR camera (all PoE 802.3af). It can also connect to WatchAI NVRs such as the WatchAI 16 Channel 2HDD 4K NVR PRO Series (NVR-8480-2HDD) via its uplink ports.

FAQs

How many devices can this switch power?
It has four PoE ports, each supplying up to 30W, within a total power budget of 65W.

What does Extender/CCTV mode do?
It enables long-distance transmission for surveillance deployments. The mode is selected using a function switch, and the switch must be rebooted to apply the change.

What are the two uplink ports for?
They are 10/100Base-T RJ45 data ports for connecting the switch to your router, NVR or existing network.

Does it need any configuration?
No. It is an unmanaged, plug-and-play switch with auto-detect and MDI/MDI-X auto-sensing.

Can it be wall mounted?
Yes, it supports both desktop and wall-mount installation.
