UA-Retrofit-Reader-Fingerprint-B - Ubiquiti UniFi Access Retrofit Reader Fingerprint
We ship from partner warehouses, so pickup is not automatic. Choose delivery at checkout and contact us if you would like to arrange pickup.
Description
Description
The Ubiquiti UniFi Access Retrofit Reader Fingerprint (SKU: UA-Retrofit-Reader-Fingerprint-B) is an indoor/outdoor OSDP reader designed for retrofit access control installations. This advanced reader combines fingerprint authentication, keypad entry, and Touch Pass support to deliver flexible, secure door access control using existing cabling infrastructure.
Engineered for seamless integration with the UniFi Retrofit Hub, the UA-Retrofit-Reader-Fingerprint-B enables organisations to upgrade their access control systems without costly rewiring. The reader supports multiple authentication methods including biometric fingerprint scanning, PIN codes via the integrated keypad, NFC cards, and mobile credentials through Touch Pass technology.
Key Features
- Fingerprint authentication for enhanced biometric security
- Integrated keypad for PIN code entry
- Touch Pass support for mobile credentials
- OSDP protocol for secure communication
- Indoor/outdoor rated for versatile installation
- Retrofit-friendly design works with existing cabling
- Compatible with UniFi Access management platform
Ideal for: Commercial buildings, office complexes, educational facilities, and multi-tenant properties seeking advanced access control with biometric authentication and flexible credential options.
Compatible Products
UniFi Access Retrofit Hub (UA-Retrofit-Hub-2) – Required DC-powered hub that supports OSDP readers and provides entry and exit control for up to two doors.
UniFi Access Card – Highly secure NFC cards for traditional card-based access control.
UACC-Retrofit-PSU-12V – 12V power supply unit for powering the Retrofit Hub and connected readers.
UACC-Junction-Utility – Junction box for clean, professional surface mounting and conduit attachment.
Frequently asked questions5 questions
What is the UniFi Access Retrofit Reader Fingerprint used for?
Which authentication methods does this reader support?
What do I need to connect this reader to?
Can this reader be installed outdoors?
What accessories are compatible with this reader?
Specifications26 specifications · 4 sections
| Overview | |
|---|---|
| Dimensions | 126.2 x 45 x 49 mm / (5 x 1.8 x 1.9") |
| UniFi Application Suite | Access |
| Fingerprint Capacity | 300 |
| Weatherproofing | IP55 |
| Mechanical | |
| Weight | 142 g (5 oz) |
| Enclosure Material | Polycarbonate, aluminum alloy |
| Mount Material | Steel |
| Mounting | Wall, gang-box mount (Included) / Junction box (Optional) |
| Hardware | |
| Indoor and Outdoor Use | Yes |
| Connectivity | RS-485 / BLE 4.2 / NFC |
| Security | OSDP v2 |
| Power Method | 12V DC |
| Max. Power Consumption | 3.5W |
| Supported Voltage Range | 12V DC |
| ESD/EMP Protection | Air: ± 8kV, contact: ± 4kV |
| Sensors | Capacitive Fingerprint |
| LEDs | R/G/B/W <a href="https://help.ui.com/hc/en-us/articles/25738084762775-UniFi-Access-Understand-Access-Device-LED-Status-Indicators" target="_blank" rel="noopener noreferrer">Learn More</a> |
| Button | (1) Factory reset |
| NFC Frequency | 13.56 MHz |
| NFC Read Range | < 30 mm (1.18'') |
| NFC Technology | ISO 14443A, 14443B, 15693 / NFC Tag 1,2,3,4,5 / MIFARE Classic / MIFARE Plus / Mifare Ultralight / MIFARE DESFire |
| Certifications | CE, FCC, IC |
| Ambient Operating Temperature | -30 to 50° C / (-22 to 122° F) |
| Ambient Operating Humidity | 5 to 90% noncondensing |
| Software | |
| Management Application | Access |
| Software Information | The software version can be checked at <a href="https://unifi.ui.com/" target="_blank" rel="noopener noreferrer">https://unifi.ui.com</a> |
