UACC-Lock-Bolt-Secure Ubiquiti Access Fail-Secure Bolt Door Lock

$185.78 AUD

20+ in stockShips from the warehouse closest to you

In stock in

BrisbaneSydneyMelbourneAdelaidePerthNorth Lakes

Pickup may be possible in North Lakes, Sydney, Brisbane, Melbourne, Adelaide and Perth

We ship from partner warehouses, so pickup is not automatic. Choose delivery at checkout and contact us if you would like to arrange pickup.

Description

The Ubiquiti Fail-Secure is an electric drop bolt lock that connects to a UniFi Access Hub (UA Hub) and ensures full security even during a power failure.

Built for strength and longevity, this type of lock remains locked when there is no power, only unlocking when electricity is applied.

This versatile lock can be installed on an aluminium, steel, or wooden single door frame, so you can place it wherever you need to enhance your door security. Offering support for a voltage range of10.5–16V DC, the lock also meets all applicable ANSI safety standards and can be connected to a UA Hub in minutes.

Features:

Remains locked during power outage

Can be installed on an aluminium, steel, or wooden door frame

ANSI-compliant design

Frequently asked questions5 questions

What happens to the lock if power is lost?

It is a fail-secure drop bolt lock, so it stays locked when there is no power and only unlocks when electricity is applied. This keeps the door secure during a power outage.

What does this lock connect to?

It connects to a UniFi Access Hub (UA Hub) and can be wired up in minutes. Wiring covers the lock 12V/NO, COM and NC connections plus the DPS positive and negative terminals.

What type of door and frame can it be installed on?

It suits a single door with an aluminium, steel or wooden frame. It uses a door frame recess mount.

What are the power requirements?

It runs on 12V DC ±10% and draws a maximum of 900mA. The listing also gives a supported voltage range of 10.5–16V DC.

How can I tell if the door is locked or unlocked?

An LED indicator shows red when the lock is locked and green when it is unlocked, with green also acting as the power indicator. An embedded door position sensor (DPS) is also built in.

Click HERE to access the Datasheet

Click HERE to access the Installation Guide

Specifications18 specifications · 1 sections

Overview
Dimensions	Lock body: 132 x 30 x 42 mm (5.2 x 1.2 x 1.7") / Door frame plate: 82 x 32 x 3 mm (3.2 x 1.3 x 0.1") / Door plate: plate: 204 x 33 x 3 mm (8 x 1.3 x 0.1")
Weight	Lock body: 350 g (12.3 oz) / Door frame plate: 22 g (0.7 oz) / Door plate: 46 g (1.6 oz)
Enclosure Material	Lock body: aluminum alloy / Door frame plate/Door plate: aluminum alloy
Lock Features · Lock Type	Fail secure
Lock Features · Support Door Type	Single door (Wooden/metal)
Lock Features · DPS	Embedded
Lock Features · Current Power	Max. 900mA
Lock Features · Support Voltage Range	12V DC ±10%
Lock Features · Wiring	(1) Lock 12V/NO (red) / (1) Lock 12V/COM (black) / (1) Lock 12V/NC (blue) / (1) DPS/- (white) / (1) DPS/+ (orange)
Lock Features · Mounting	Door frame recess mount
Lock Features · LED Indicator	Red: locked / Green: unlocked & power indicator
Door Status Contact · Type	Dry contact
Door Status Contact · Logic	Door Open: DPS/+ & DPS/- = Open / Door Close: DPS/+ & DPS/- = Short
Door Status Contact · Rating	Max. 30V DC, 0.5A
Ambient Storage Temperature	-20 to 70° C (-4 to 158° F)
Ambient Operating Temperature	-10 to 60° C (14 to 140° F)
Ambient Operating Humidity	5 to 90% noncondensing
Certifications	FCC, IC, CE
