Manufacturer's photos. Where a power lead is pictured, an AU one is provided.
UACC-Lock-Strike-Safe Ubiquiti Access Door Lock (Fail Safe)
We ship from partner warehouses, so pickup is not automatic. Choose delivery at checkout and contact us if you would like to arrange pickup.
We ship from partner warehouses, so pickup is not automatic. Choose delivery at checkout and contact us if you would like to arrange pickup.
Description
Description
The Ubiquiti Fail-Safe Strike Lock is an electric strike lock that connects to a UniFi Access Hub (UA Hub) and is designed to unlock during power failure. This ensures safe exit or entry in an emergency.
Built for strength and longevity, the Fail-Safe lock remains unlocked with no power, only locking again when electricity is applied.
It is offered with Standard (15mm) and Narrow (8mm) lock slot depth support.
The Standard strike lock has a holding force of up to 1,200 kg (2,500 lb).
The Narrow strike lock has a holding force of up to 227 kg (500 lb)
This versatile lock can be installed on an aluminium, steel, or wooden door frame, so you can place it wherever you need to enhance your door security. This 12V DC-powered lock also meets all applicable ANSI safety standards and can be connected to a UA Hub in minutes.
Features:
Unlocks during power outage
Can be installed on an aluminium, steel, or wooden door frame
ANSI-compliant design
Specifications17 specifications · 1 sections
| Overview | |
|---|---|
| Dimensions | Lock body: 80 x 40 x 35 mm (3.2 x 1.6 x 1.4") / Short front plate: 124 x 32 x 3 mm (4.9 x 1.3 x 0.1") / Long front plate: 202 x 36 x 3 mm (7.9 x 1.4 x 0.1") |
| Weight | Lock body: 185 g (6.5 oz) / Short front plate: 50 g (1.8 oz) / Long front plate: 130 g (4.6 oz) |
| Enclosure Material | Lock body: zinc alloy / Front plate: aluminum alloy / Latches: stainless steel |
| Lock Features · Lock Type | Fail safe |
| Lock Features · Support Door Type | Single door (Wooden/metal) |
| Lock Features · Holding Force | 1,200 kg (2,645 lb) |
| Lock Features · Current Power | 400mA ±10% |
| Lock Features · Support Voltage Range | 12V DC ±10% |
| Lock Features · Wiring | (1) Lock 12V/NC (red) / (1) Lock 12V/COM (black) |
| Lock Features · Mounting | Door frame recess mount |
| Door Status Contact · Type | Dry contact |
| Door Status Contact · Logic | Door Open: DPS/+ & DPS/- = Open / Door Close: DPS/+ & DPS/- = Short |
| Door Status Contact · Rating | Max. 30V DC, 0.1A |
| Ambient Storage Temperature | -20 to 70° C (-4 to 158° F) |
| Ambient Operating Temperature | -10 to 60° C (14 to 140° F) |
| Ambient Operating Humidity | 5 to 90% noncondensing |
| Certifications | FCC, IC, CE |
