Manufacturer's photos. Where a power lead is pictured, an AU one is provided.
SKU:
UACC-PoE+-USBC
UACC-PoE+-USBC Ubiquiti PoE Integrated AC Adapter
$100.85 AUD
Unit price
/
Unavailable
20+ in stockShips from the warehouse closest to you
BrisbaneSydneyMelbourneAdelaidePerthNorth Lakes (none in stock)
Pickup may be possible in Sydney, Brisbane, Melbourne, Adelaide and Perth
We ship from partner warehouses, so pickup is not automatic. Choose delivery at checkout and contact us if you would like to arrange pickup.
Description
Description
An AC adapter with integrated PoE, enabling the UniFi Cloud Gateway device to support PoE output on a single port.
Features:
Delivers up to 30W of PoE+
Supports wall mount, DIN rail and floating mount*
Lockable latch designed for power cord security
*DIN rail and floating mount sold separately
Frequently asked questions5 questions
What is the UACC-PoE+-USBC used for?
It is an AC adapter with integrated PoE that lets a UniFi Cloud Gateway device provide PoE output on a single port. It delivers up to 30W of PoE+.
What are the power output specifications?
The Type-C output is 5V at 5A, and the PoE+ output is 48V at 0.65A. The adapter accepts 100–240V AC at 50/60Hz, with a maximum input current of 1.5A.
Which UniFi devices is it compatible with?
Listed compatible devices include the UCG-Ultra, UCG-Max, UXG-Lite and UXG-Max. The compatibility list on this page continues beyond these models.
What mounting options and cable lengths does it offer?
It supports wall mount, DIN rail and floating mount. The cable is 150 cm in total, including 30 cm split Type-C/Ethernet ends, and the power cord is 180 cm. A lockable latch secures the power cord.
What are its operating conditions and size?
It operates at 0 to 40°C and 10 to 95% noncondensing humidity. It measures 146 x 62 x 42 mm and weighs 358 g.
Specifications24 specifications · 1 sections
| Overview | |
|---|---|
| Dimensions | 146 x 62 x 42 mm (5.7 x 2.4 x 1.7") |
| Weight | 358 g (12.6 oz) |
| Length | Cable: 150 cm (4.9 ft) total, including 30 cm split Type-C/Ethernet ends / Power cord: 180 cm (5.9 ft) |
| Output Voltage | Type-C: 5V@ 5A / PoE+: 48V@ 0.65A |
| Rated Voltage | 100–240V AC at 50/60Hz |
| 4-pair Powering | Pins 1, 2, 4, 5 (+) and 3, 6, 7, 8 (-) |
| Clamping Protection | 11V data, 60V power |
| Data In / PoE | RJ45 shielded socket |
| Input Current | 1.5A max. |
| Inrush Current | 120A |
| Efficiency | 82% |
| Switching Frequency | 65 kHz |
| Output Ripple | 1% max. |
| Line Regulation | ≤ 5% |
| Load Regulation | ≤ 5% |
| Max. Surge Discharge | 1500A (8/20 μs) power |
| Peak Pulse Current | 36A (10/1000 μs) data |
| Response Time | <1 ns |
| Shunt Capacitance | <5 pF data |
| Surge Protection | Difference and common mode |
| Ambient Storage Temperature | -30 to 70°C (-22 to 158° F) |
| Ambient Operating Temperature | 0 to 40° C (32 to 104° F) |
| Ambient Operating Humidity | 10 to 95% noncondensing |
| Certifications | CE, FCC, IC, UL, UKCA, CCC, RoHS |
Source: Ubiquiti technical specifications, checked 29 Oct 2026.Model UACC-PoE+-USBC · Ubiquiti's spec sheet
