UACC‑Rack‑12U‑Wall‑450‑P – Ubiquiti 12U Wall‑Mount Rack Cabinet (Perforated Door)
We ship from partner warehouses, so pickup is not automatic. Choose delivery at checkout and contact us if you would like to arrange pickup.
Description
Description
The Ubiquiti UACC‑Rack‑12U‑Wall‑450‑P is a professional 12U wall‑mount rack cabinet designed for secure, space‑efficient network deployments where airflow is critical. Manufactured from durable SPCC steel and finished in a clean white powder coat, this cabinet delivers long‑term reliability and a modern appearance.
Supplied fully assembled, the UACC‑Rack‑12U‑Wall‑450‑P features a lockable perforated front door to maximise ventilation for active networking equipment. Integrated cooling fans, removable lockable side panels and adjustable mounting rails provide excellent airflow, easy access and simplified installation.
Key Features:
- 12U wall‑mount rack cabinet with up to 50 kg load capacity
- Perforated lockable front door for enhanced airflow
- Integrated fan module with ≤50 dB acoustic noise
- Adjustable mounting depth from 283–305 mm
- Removable and lockable side panels
- Fully assembled for rapid deployment
Ideal for:
Small and medium businesses, retail sites, equipment rooms, schools and home labs requiring improved ventilation for network hardware.
Compatible Products:
Ubiquiti UniFi rack‑mount switches
Ubiquiti Cloud Gateways
Ubiquiti NVR and security appliances
Ubiquiti rack shelves and mounting accessories
FAQs:
Is the rack supplied assembled? Yes, it ships fully assembled.
Does it support active cooling? Yes, integrated fans are included.
What device depth is supported? Devices up to 325 mm deep are supported.
Frequently asked questions3 questions
Is the rack supplied assembled?
Does it support active cooling?
What device depth is supported?
Specifications19 specifications · 1 sections
| Overview | |
|---|---|
| Dimensions | Packaging: 580 x 675 x 735 mm (22.8 x 26.6 x 28.9") / Rack: 550 x 450 x 635 mm (21.7 x 17.7 x 25") |
| Weight | Packaging: 22 kg (48.5 lb) / Rack: 17.8 kg (39.2 lb) |
| Enclosure Material | SPCC steel / Door/side panels: 0.8 mm (0.03") / Main body: 0.8 mm (0.03") / Posts: 2 mm (0.08") |
| Color | White |
| Treatment | Powder coating |
| Rack Features · U Height | 12U |
| Rack Features · Rack Type | 4 post, enclosed cabinet |
| Rack Features · Mounting Hole Type | Square |
| Rack Features · Adjustable Mounting Depth | Default 283 mm (11.1") / Max. 305 mm (12") / Adjustable pitch 22 mm (0.9") |
| Rack Features · Max. Weight Capacity | 50 kg (110 lb) |
| Rack Features · Front Door | Perforated / Default left-hand outswing, reversible |
| Rack Features · Side Panels | (2) Solid, removable and lockable |
| Rack Features · Mounting | Wall mount |
| Rack Features · Fan Module | (2) Pre-installed 120 x 120 x 38 mm AC fan units |
| Rack Features · Acoustic Noise | ≤ 50 dB(A) sound pressure level |
| Rack Features · Cable Entry Opening | (1) Rear wall: 350 x 100 mm (13.8 x 3.9") / (1) Top: 336.5 x 52.5 mm (13.2 x 2.1") / (1) Bottom: 336.5 x 52.5 mm (13.2 x 2.1") |
| Rack Features · Security | (1) Front door lock / (4) Side panel locks / (2) Keys |
| Rack Features · Standard | CE; EIA/ECA-310-E; RoHS |
| Supported Devices | Compatible with Ubiquiti rack-mount devices up to 325 mm in depth. / / Note: 325 mm devices can be installed when the mounting depth is set to 305 mm (max), but DC power backup is not supported due to limited rear-side clearance. |
