USW-Pro-48 Ubiquiti UniFi Switch Pro 48 Non PoE

Q: How is the switch powered, and does it have power redundancy?

It has an internal 60W AC\/DC power supply with a universal 100–240V AC, 50\/60 Hz input. A USP RPS DC input is also provided for DC power backup, and maximum power consumption is 60W.

$1,256.64 AUD

Out of stock

BrisbaneSydneyMelbourneAdelaidePerthNorth Lakes

Description

Layer 3 switch with (48) GbE RJ45 ports and (4) 10G SFP+ ports.

The Switch Pro 48 (USW Pro 48) is a fully managed switch with (48) GbE RJ45 ports and (4) 10G SFP+ ports.

The USW Pro 48 combines a rich set of Layer 2 features with advanced Layer 3 tools including inter-VLAN routing, static routing, and a DHCP server. The USW Pro 48 is an ideal aggregation and access layer switch for any UniFi system. It combines innovative, near-silent cooling capability with SmartPower RPS (USP RPS) power redundancy.

The switch can also be monitored and configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

Features:

(1) 1.3" LCM color touchscreen with AR switch management
(48) GbE RJ45 ports
(4) 10G SFP+ ports
(1) USP RPS DC input
Near-silent cooling
Layer 3 switching features

Managed with the UniFi Network application: Version 5.12.11 and later

Frequently asked questions5 questions

Does the USW-Pro-48 support PoE?

No. This is the Non PoE model, so it does not supply power over Ethernet to connected devices. It has 48 GbE RJ45 ports and 4 10G SFP+ ports.

What Layer 3 features does it offer?

It provides inter-VLAN routing, static routing and a DHCP server alongside its Layer 2 features. It supports up to 1,000 VLANs and 256 IPv4 static routes.

What ports does the USW-Pro-48 have?

It has 48 RJ45 ports running at 1G, 100M or 10M, plus 4 SFP+ ports running at 10G or 1G. Switching capacity is 176 Gbps.

How is the switch powered, and does it have power redundancy?

It has an internal 60W AC/DC power supply with a universal 100–240V AC, 50/60 Hz input. A USP RPS DC input is also provided for DC power backup, and maximum power consumption is 60W.

How is the switch managed?

It is managed with the UniFi Network web application and mobile app, version 5.12.11 or later. It also has a 1.3" colour touchscreen with AR switch management.

Click HERE to access the Datasheet

Click HERE to access the Installation Guide

Specifications31 specifications · 4 sections

Overview
Dimensions	442 x 285 x 44 mm / (17.4 x 11.2 x 1.7")
Port Layout · 1 GbE RJ45	48 / (1G/100M/10M)
Port Layout · 10G SFP+	4 / (10G/1G)
Redundancy	DC Power Backup
Form Factor	Rack mount (1U)
Performance
Switching Capacity	176 Gbps
Total Non-Blocking Throughput	88 Gbps
Forwarding Rate	131 Mpps
Supported VLANs	1,000
MAC Address Table Size	16,000
IPv4 Static Routes	256
Packet Buffer Size	4 MB
Access Lists · IPv4	128
Access Lists · MAC	128
Hardware
Max. Power Consumption	60W
Power Method	(1) Universal input, 100–240V AC, 50/60 Hz / (1) USP RPS DC input
Power Input Method	AC input
Power Supply	AC/DC, internal, 60W
Supported Voltage Range	100–240V AC
Management	Ethernet / AR
Heat Dissipation	204.7 BTU/hr
Weight	Without mounting brackets: 4 kg (8.8 lb) / With mounting brackets: 4.1 kg (9 lb)
Enclosure Material	SGCC steel
Mount Material	SGCC steel
Supported Rack Depth	400~1200 mm / (15.7-47.2")
LCM Display	1.3" touchscreen
ESD Protection	Air: ± 16kV, contact: ± 12kV
Ambient Operating Temperature	-5 to 40° C (23 to 104° F)
Ambient Operating Humidity	10 to 90% noncondensing
Certifications	CE, FCC, IC, Anatel: 00469-21-08356
Software
Application Requirements · UniFi Network	Version 5.12.11 and later
