USW-Enterprise-8-PoE Ubiquiti UniFi Switch Enterprise 8 PoE

$739.20 AUD

20+ in stockShips from the warehouse closest to you

BrisbaneSydneyMelbourneAdelaidePerthNorth Lakes

Pickup may be possible in Sydney, Brisbane, Melbourne, Adelaide and Perth

We ship from partner warehouses, so pickup is not automatic. Choose delivery at checkout and contact us if you would like to arrange pickup.

Description

The Switch Enterprise 8 PoE (USW Enterprise 8 PoE) is a fully managed, Layer 3* switch with (8) 2.5GbE, 802.3at PoE+ RJ45 ports and (2) 10G SFP+ ports.

The USW Enterprise 8 PoE also features a 1.3' LCM color touchscreen that concisely displays key system and connection insights.

This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

Features:

(1) 1.3' LCM color touchscreen with AR switch management
(8) 2.5GbE, 802.3at PoE+ RJ45 ports
(2) 10G SFP+ ports
120W total PoE supply
Wall-mountable (kit included)

* Layer 3 switching will become available in a future firmware update.

Managed with the UniFi Network application: Version 6.3.51 and later

Frequently asked questions5 questions

What ports does the USW-Enterprise-8-PoE have?

It has eight 2.5GbE RJ45 ports, all with PoE+, and two 10G SFP+ ports. The RJ45 ports support 2.5G, 1G, 100M and 10M speeds, and the SFP+ ports support 10G and 1G.

How much PoE power does this switch provide?

It supplies up to 120W of total PoE power across its eight PoE+ ports. Each port can deliver up to 32W.

How is the switch managed?

It is a fully managed switch, configured and monitored through the UniFi Network web application and mobile app, from version 6.3.51 onwards. It also has a 1.3-inch colour touchscreen showing key system and connection information.

Does the USW-Enterprise-8-PoE support Layer 3 switching?

Layer 3 switching is not yet available and will arrive in a future firmware update. The switch supports 256 IPv4 static routes.

Can this switch be wall-mounted?

Yes, it is wall-mountable and a mounting kit is included. It is a compact desktop unit measuring 200 x 248 x 44 mm and weighing 2.4 kg.

Customer reviews

5.0 · 3 reviews

Write a review

5 ★ 34 ★ 03 ★ 02 ★ 01 ★ 0

★★★★★Collected by reviews.io · Nov 2024

This is a great switch with 8 ports of PoE all 2.5Gbe and two 10gbe sfp+ ports. I am currently using it in my rack with a rack Mount kit but I have the UniFi addiction now and have bought a bigger 24-port single space 10gbe campus switch and this usw-enterprise-poe is going to my home theatre area. The only downside of that is I cannot turn off the lights in the software. I will need to physically tape them up or box them so I can retain a purely dark cinematic experience. Otherwise it is a very good switch. Gets a little warm. Has a nice mounting kit included for mounting under a desk.

★★★★★Collected by reviews.io · Oct 2024

Works very well although does get quite warm to the touch. Plenty of POE for most things.

Tim

★★★★★Collected by reviews.io · Oct 2023

High quality. High performance. Easy to deploy.

Gerry

Click HERE to access the Datasheet

Click HERE to access the Installation Guide

Specifications34 specifications · 4 sections

Overview
Dimensions	200 x 248 x 44 mm / (7.9 x 9.8 x 1.7")
Port Layout · 2.5 GbE RJ45	8 (All PoE+) / (2.5G/1G/100/10M)
Port Layout · 10G SFP+	2 / (10G/1G)
Max. PoE Output	Up to PoE+
Total PoE Availability	120W
Form Factor	Compact desktop
Performance
Switching Capacity	80 Gbps
Total Non-Blocking Throughput	40 Gbps
Forwarding Rate	60 Mpps
Supported VLANs	1,000
MAC Address Table Size	16,000
IPv4 Static Routes	256
Packet Buffer Size	1.5 MB
Access Lists · IPv4	12
Access Lists · MAC	10
Hardware
PoE Ports · PoE+	8
Max. PoE Wattage per Port by PSE · PoE+	32W
Max. Power Consumption	30W (Excluding PoE Output) / 150W (Including PoE Output)
Power Method	Universal input, 100–240V AC, 50/60 Hz
Power Input Method	AC input
Power Supply	AC/DC, internal, 150W
Supported Voltage Range	100–240V AC
Management	Ethernet / AR
Heat Dissipation	102.4 BTU/hr (Excluding PoE Output)
Weight	2.4 kg (5.3 lb)
Enclosure Material	Polycarbonate
Mount Material	Polycarbonate
Supported Rack Depth	400~1200 mm / (15.7-47.2")
LCM Display	1.3" touchscreen
ESD Protection	Air: ± 16kV, contact: ± 12kV
Ambient Operating Temperature	-5 to 45° C (23 to 113° F)
Ambient Operating Humidity	10 to 90% noncondensing
Certifications	CE, FCC, IC, Anatel: 06645-23-08356
Software
Application Requirements · UniFi Network	Version 6.3.51 and later
