USW-Flex-XG Ubiquiti UniFi Switch Flex XG

Q: What ports does the USW-Flex-XG have?

It has four 10GbE RJ45 ports and one GbE RJ45 port (1G\/100M\/10M) that accepts 802.3at PoE+ input. It is a fully managed, multi-gigabit Layer 2 switch.

$554.23 AUD

20+ in stockShips from the warehouse closest to you

BrisbaneSydneyMelbourneAdelaidePerthNorth Lakes

Pickup may be possible in Sydney, Brisbane, Melbourne, Adelaide and Perth

We ship from partner warehouses, so pickup is not automatic. Choose delivery at checkout and contact us if you would like to arrange pickup.

Description

Layer 2 switch with (4) 10GbE RJ45 ports and (1) GbE, PoE+ RJ45 input.

The Switch Flex XG (USW Flex XG) is a fully managed, mult-gigabit, Layer 2 switch with (4) 10GbE RJ45 ports and (1) GbE PoE input.

The USW Flex XG sports slim, compact housing and can be mounted on a desktop*. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

Features:

(1) GbE, 802.3at PoE+ RJ45 input
(4) 10GbE RJ45 ports
Compact, slim housing
Can be powered with a 5V, 5A USB-C adapter

*Fanless Switch, Do not stack other hardware on the USW Flex XG, will affect heat dissipation

Frequently asked questions5 questions

What ports does the USW-Flex-XG have?

It has four 10GbE RJ45 ports and one GbE RJ45 port (1G/100M/10M) that accepts 802.3at PoE+ input. It is a fully managed, multi-gigabit Layer 2 switch.

How is the USW-Flex-XG powered?

It can be powered by PoE+ through its GbE RJ45 port (44V-57V) or by a 5V, 5A USB-C adapter (4.8-5.2V DC). Maximum power consumption is 25W.

Can the USW-Flex-XG be mounted on a desk or wall?

Yes, its compact, slim housing (135 x 185 x 32 mm) suits desktop or wall mounting. It is fanless, so do not stack other hardware on top, as this will affect heat dissipation.

How is the USW-Flex-XG managed?

It is managed through the UniFi Network web application and mobile app, so it can be monitored or configured from anywhere. It requires UniFi Network version 6.1.67 or later.

What are the switching performance figures for the USW-Flex-XG?

It offers 82 Gbps switching capacity, 41 Gbps total non-blocking throughput and a 61 Mpps forwarding rate. It supports 1,000 VLANs and a 16,000-entry MAC address table.

Click HERE to access the Datasheet

Click HERE to access the Installation Guide

Specifications26 specifications · 4 sections

Overview
Dimensions	135 x 185 x 32 mm / (5.3 x 7.3 x 1.3")
Port Layout · 1 GbE RJ45	1 / (1G/100M/10M)
Port Layout · 10 GbE RJ45	4
Form Factor	Compact desktop, wall
Performance
Switching Capacity	82 Gbps
Total Non-Blocking Throughput	41 Gbps
Forwarding Rate	61 Mpps
Supported VLANs	1,000
MAC Address Table Size	16,000
Packet Buffer Size	1.5 MB
Access Lists · IPv4	12
Access Lists · MAC	10
Hardware
Max. Power Consumption	25W
Power Method	(1) PoE+ / (1) USB Type-C, 5V DC, 5A
Power Input Method	USB Input / PoE
Power Supply	AC/DC, external, 25W
Supported Voltage Range	4.8—5.2V DC/USB / 44V—57V PoE
Management	Ethernet
Heat Dissipation	85.3 BTU/hr
Weight	1.2 kg (2.7 lb)
Enclosure Material	Polycarbonate
ESD Protection	Air: ± 16kV, contact: ± 12kV
Ambient Operating Temperature	-5 to 45° C (23 to 113° F)
Ambient Operating Humidity	10 to 90% noncondensing
Certifications	CE, FCC, IC, Anatel: 06606-25-08356
Software
Application Requirements · UniFi Network	Version 6.1.67 and later
