Manufacturer's photos. Where a power lead is pictured, an AU one is provided.
SKU:
UDM-PRO
UDM-Pro Ubiquiti UniFi Dream Machine Pro
$819.64 AUD
Unit price
/
Unavailable
20+ in stockShips from the warehouse closest to you
Brisbane (none in stock)SydneyMelbourneAdelaidePerthNorth Lakes (none in stock)
Pickup may be possible in Sydney, Melbourne, Adelaide and Perth
We ship from partner warehouses, so pickup is not automatic. Choose delivery at checkout and contact us if you would like to arrange pickup.
Description
Description
The Dream Machine Pro (UDM Pro) is an enterprise-grade UniFi OS Console that offers a scalable networking experience and comprehensive platform for multi-application use.
The UDM Pro is an all-in-one networking console that runs every UniFi OS application, like Network and Protect. It features a built-in security gateway, 10G SFP+ WAN support, an 8-port Gigabit switch, and network video recorder that supports compatible 3.5" hard disk drives (HDDs).
Features:
Runs every UniFi OS application, including the pre-installed UniFi Network
8-port switch with 1GbE RJ45 and 10G SFP+ ports
Integrated security gateway and UniFi Protect-ready network video recorder that supports compatible 3.5" HDDs
Enterprise-class internet threat management, deep packet inspection, and WiFi AI functionality
Powered by a fast, 1.7 GHz quad-core processor
1U-sized, rack-mountable console
Allows you to easily scale your deployment by connecting additional UniFi devices
Connect a USP RPS to create an uninterruptible network
Frequently asked questions5 questions
What is the UDM-Pro designed to do?
It is an all-in-one UniFi OS Console that combines a security gateway, an 8-port Gigabit switch and a network video recorder. It runs every UniFi OS application, including the pre-installed UniFi Network and UniFi Protect.
What ports does the UDM-Pro have?
It has 9 x 1GbE RJ45 ports and 2 x 10G SFP+ ports. By default, WAN uses one 10G SFP+ port and one GbE RJ45 port, and up to 8 WAN ports are supported.
Can the UDM-Pro record video from cameras?
Yes, it includes a UniFi Protect-ready network video recorder with one 3.5" HDD bay for compatible drives. It can manage up to 24 HD, 14 2K or 8 4K cameras.
How many devices and users can it manage?
It can manage 100+ UniFi devices and 150 access hubs, with 1,000+ simultaneous users connected. IDS/IPS throughput is 3.5 Gbps.
How is the UDM-Pro powered and mounted, and does it support backup power?
It has an internal 50W AC/DC power supply with a 100–240V AC input and uses a maximum of 33W. It is a 1U rack-mount unit and supports a USP-RPS DC input for power backup.
Customer reviews
5.0
· 2 reviews
★★★★★Collected by reviews.io · Sep 2023
Great product
AaronSpecifications33 specifications · 4 sections
| Overview | |
|---|---|
| Dimensions | 442.4 x 43.7 x 285.6 mm / (17.4 x 1.7 x 11.2") |
| Managed UniFi Devices | 100+ |
| Managed Cameras | (24) HD / (14) 2K / (8) 4K |
| Managed Access Hubs | 150 |
| Simultaneous Users Connected | 1,000+ |
| Max. WAN Port Count | 8 |
| Default WAN Ports | (1) 10G SFP+ / (1) GbE RJ45 |
| Port Layout · 1 GbE RJ45 | 9 / (1G/100M/10M) |
| Port Layout · 10G SFP+ | 2 / (10G/1G) |
| IDS/IPS Throughput | 3.5 Gbps |
| Form Factor | Rack mount (1U) |
| Redundancy | Shadow Mode (VRRP) Gateway Failover / DC Power Backup |
| Security | |
| IDS/IPS Signatures | 55,000+ / with CyberSecure |
| Networking | |
| MAC Address Table Size | 4,000 |
| Hardware | |
| NVR Storage | (1) 3.5" NVR HDD bay |
| Max. Power Consumption | 33W |
| Power Method | (1) Universal AC input, 100–240V AC, 50/60 Hz / (1) USP-RPS DC input |
| Power Supply | AC/DC, internal, 50W |
| Supported Voltage Range | 100–240V AC |
| Heat Dissipation | 112 BTU/hr |
| Processor | Quad-core ARM® Cortex®-A57 at 1.7 GHz |
| System Memory | 4 GB |
| On-board Storage | 16 GB |
| Weight | 3.9 kg (8.6 lb) |
| Enclosure Material | Aluminium CNC, SGCC steel |
| Mount Material | SGCC steel |
| LCM Display | 1.3" touchscreen |
| Management | Ethernet / Bluetooth |
| Button | (1) Factory reset |
| ESD/EMP Protection | Air: ± 15kV, contact: ± 8kV |
| Ambient Operating Temperature | -10 to 40° C (14 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC, Anatel: 01136-20-08356, SRRC |
Source: Ubiquiti technical specifications, checked 6 Nov 2026.Model UDM-PRO · Ubiquiti's spec sheet
