USW-LR-Switch-8-PoE - Ubiquiti Long-Range Switch 8 PoE
- Order today · 20 NovAdded to our next Ubiquiti order
- Ship date confirmedBy email once Ubiquiti allocates stock
- Delivered · by 10 – 21 DecOur aim: 14–21 working days from your order
Confirmation now, tracking the moment it ships.
How pre-orders work
How pre-orders work
We are just not quite the same as many of the other online stores. I know it is easy to say that, but we just aren't.
The Tech Geeks, under their parent company Twelve Times (Worldwide) Pty Ltd trade in Australia, New Zealand and the United Kingdom.
This allows us to purchase stock from suppliers from locations where they have it available. We are then able to import those products directly, along with providing localised Warranty and Replacement as required.
We only list items that we know have been, or are about to be released to us and since we purchase only in small batches these are often flown in on short time frames.
We list on each product our expected shipments and ones that we have already sent out to customers. Please use these dates as a guideline as we always suggest 14-21 days just to allow for air freight or customs hold ups.
Want to know when new product stock is released? why not sign up here to our alerts.
Description
Description
The Ubiquiti Long-Range Switch 8 PoE (SKU: USW-LR-Switch-8-PoE) is a compact, high-power PoE+++ switch designed to deliver power and data far beyond the limits of standard copper Ethernet. With support for Long-Range Endpoints at distances up to 800 metres over a single cable, it is built for remote cameras, access devices and IoT sensors in locations where local power is unavailable.
Standard copper Ethernet reaches 100 metres. The USW-LR-Switch-8-PoE removes the need for separate fibre and electrical supply on long runs, simplifying deployments across large sites. A 1.3" touchscreen sits on the front of the unit, and a rackmount accessory is included so you can install it in a rack or use it as a compact desktop unit.
It provides 630W of total PoE availability across eight PoE+++ ports, with up to 90W per port, and is powered by an internal 660W AC/DC supply with universal 100–240V AC input. It is managed through UniFi, bringing remote infrastructure into the same building operating system as your network and physical security, with licence-free operation.
Key Features
- Long-range PoE: supports Long-Range Endpoints at distances up to 800 m over a single Ethernet cable
- (8) PoE+++ ports: 10/100M RJ45 ports, all with PoE+++ output
- 630W total PoE availability with up to 30W (PoE+), 60W (PoE++) and 90W (PoE+++) per port
- Uplink options: (1) 1 GbE RJ45 port and (1) 1G SFP port
- 1.3" touchscreen LCM display
- Rackmount accessory included; form factor is rack mount / compact desktop
- Layer 2 features including 256 VLANs, STP & RSTP, port isolation, port mirroring, storm control, jumbo frames, LLDP-MED and voice VLAN
- Switching capacity of 3.6 Gbps with a 2.67 Mpps forwarding rate
- Internal 660W AC/DC power supply, 100–240V AC, 50/60 Hz
- Operating temperature of -5 to 45°C; SGCC steel mount material; NDAA compliant
- Dimensions: 210 x 260 x 43.7 mm; weight 2.6 kg (3.13 kg with mounting brackets)
Ideal for: installers, system integrators, IT managers and businesses deploying remote CCTV cameras, access control devices and IoT sensors at the edge of a site, such as car parks, yards, campuses and outbuildings, where running fibre and local power is impractical.
Compatible Products
Outdoor Long-Range Endpoint (UACC-LR-Endpoint)
Required for long-range performance and designed exclusively for the Long-Range Switch 8 PoE. It features a long-range 10/100 MbE PoE+++ port, is IPX5-rated, includes built-in surge protection and supports single and dual mount configurations. Long-range is enabled on one of the eight ports per endpoint.
UniFi Official Outdoor Cable
Used to achieve the available PoE power at the Long-Range Endpoint over distances up to 800 metres.
UniFi Network and Physical Security
Manage your switch alongside UniFi network and physical security devices from a single platform.
Frequently asked questions5 questions
How far can the Long-Range Switch 8 PoE deliver power and data?
Do I need a Long-Range Endpoint?
What is the total PoE budget?
What mounting options are available?
What are the uplink options?
Specifications29 specifications · 3 sections
| Overview | |
|---|---|
| Dimensions | 210 x 260 x 43.7 mm / (8.3 × 10.2 × 1.7") |
| Port Layout · 100 MbE RJ45 | 8 (All PoE+++) / (100M/10M) |
| Port Layout · 1 GbE RJ45 | 1 / (1G/100M/10M) |
| Port Layout · 1G SFP | 1 |
| Max. PoE Output | Up to PoE+++ |
| Total PoE Availability | 630W |
| Form Factor | Rack Mount / Compact Desktop |
| Performance | |
| Switching Capacity | 3.6 Gbps |
| Total Non-Blocking Throughput | 1.8 Gbps |
| Forwarding Rate | 2.67 Mpps |
| Supported VLANs | 256 |
| MAC Address Table Size | 8,192 |
| Hardware | |
| PoE Ports · PoE+++ | 8 |
| Max. PoE Wattage per Port by PSE · PoE+ | 30W |
| Max. PoE Wattage per Port by PSE · PoE++ | 60W |
| Max. PoE Wattage per Port by PSE · PoE+++ | 90W |
| Max. Power Consumption | 11W (Excluding PoE Output) / 720W (Including PoE Output) |
| Power Method | (1) Universal input, 100–240V AC, 50/60 Hz |
| Power Input Method | AC input |
| Power Supply | AC/DC, internal, 660W |
| Supported Voltage Range | 100–240V AC |
| Weight | Without mounting brackets: / 2.6 kg (5.7 lb) / With mounting brackets: / 3.13 kg (6.9 lb) |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| LCM Display | 1.3" touchscreen |
| ESD Protection | Air: ± 15kV, contact: ± 8kV |
| Ambient Operating Temperature | -5 to 45° C (23 to 113° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
