SKU: USW-Pro-XG-8-PoE

USW-Pro-XG-8-PoE Ubiquiti UniFi Compact 8-port Etherlighting Switch

Name: USW-Pro-XG-8-PoE Ubiquiti UniFi Compact 8-port Etherlighting Switch
Brand: Ubiquiti
SKU: USW-Pro-XG-8-PoE
Price: 999.17 AUD
Availability: InStock

$999.17 AUD

Add to cart, then request a quote for our best price.

Description

Compact desktop/wall-mountable, professional-grade 8-port, Layer 3 Etherlighting™ PoE++ switch with (8) 10 GbE and (2) 10G SFP+ ports.

Click HERE to access the Datasheet

Click HERE to access the Installation Guide

Specifications33 specifications · 4 sections

Overview
Dimensions	210.4 x 173.8 x 43.7 mm / (8.28 x 6.84 x 1.7")
Port Layout · 10 GbE RJ45	8 (All PoE++) / (10G/5G/2.5G/1G/100M)
Port Layout · 10G SFP+	2 / (10G/1G)
Max. PoE Output	Up to PoE++
Total PoE Availability	155W
Form Factor	Compact desktop, wall
Performance
Switching Capacity	200 Gbps
Total Non-Blocking Throughput	100 Gbps
Forwarding Rate	149 Mpps
Supported VLANs	1,000
MAC Address Table Size	32,000
IPv4 Static Routes	256
Packet Buffer Size	2 MB
Access Lists · IPv4	128
Access Lists · MAC	128
Hardware
PoE Ports · PoE++	8
Max. PoE Wattage per Port by PSE · PoE	15.4W
Max. PoE Wattage per Port by PSE · PoE+	30W
Max. PoE Wattage per Port by PSE · PoE++	60W
Max. Power Consumption	61W (Excluding PoE output) / 210W (Including PoE output)
Power Method	AC/DC Adapter (included)
Power Input Method	DC input
Power Supply	AC/DC, external, 210W
Supported Voltage Range	50–57V DC
Management	Ethernet
Weight	1.6 kg (3.5 lb)
Enclosure Material	SGCC steel
Mount Material	Polycarbonate
ESD Protection	Air: ± 30kV, contact: ± 30kV
Ambient Operating Temperature	-5 to 45° C (23 to 113° F)
Ambient Operating Humidity	10 to 90% noncondensing
Certifications	CE, FCC, IC, Anatel: 04322-25-08356
Software
Application Requirements · UniFi Network	Version 9.0.114 and later
