WG9043 - WatchGuard Firebox M4850/M5850/M6850 2-port 100GbE QSFP28 OCP Module
Description
Description
The WatchGuard Firebox M4850/M5850/M6850 2-port 100GbE QSFP28 OCP Module (SKU: WG9043) is an optional OCP 3.0 network card that adds two 100 Gbps QSFP28 ports to your Firebox High Rackmount appliance. It is designed for organisations that need ultra-high-speed connectivity for data centre, campus and core network deployments, and it slots straight into the dedicated module bay at the rear of the appliance.
The Firebox M4850, M5850 and M6850 each include an OCP 3.0 PCIe Gen 5 x8 module bay. The WG9043 is one of the optional cards available for this bay, giving you the flexibility to scale your 100GbE network capacity as your traffic grows, without replacing the firewall.
Key Features
- 2 x 100 Gbps QSFP28 interfaces, which operate with compatible QSFP28 transceivers
- OCP 3.0 (Open Compute Project) network card format
- Designed specifically for the Firebox M4850, M5850 and M6850 rackmount firewalls
- Installs into the rear module bay (OCP 3.0 PCIe Gen 5 x8)
- Adds high-speed interfaces to your existing built-in 1G, 10G and 25G ports
- Fully integrated with Fireware: install the module, then configure the new interfaces in your Firebox configuration
Installation Notes
Power off the Firebox before inserting the card. Remove the module bay cover plate, then align the network card with the OCP slot rails and slide it into place. The module must be installed before its interfaces can be configured.
Ideal for: Data centre edge and core deployments, large distributed enterprises, campus networks and MSPs who need to add native 100GbE connectivity to a WatchGuard Firebox High Rackmount appliance.
Compatible Products
WatchGuard Firebox M4850
WatchGuard Firebox M5850
WatchGuard Firebox M6850
FAQs
Which Firebox models is the WG9043 compatible with?
The 2-port 100G QSFP28 OCP 3.0 card is available only for the Firebox M4850, M5850 and M6850.
What type of expansion slot does it use?
It uses the OCP 3.0 module bay found on the rear of the M4850, M5850 and M6850, which is PCIe Gen 5 x8.
Do I need to power off the Firebox to install it?
Yes. The Firebox must be powered off before you insert an OCP network card.
Can I configure the ports straight away?
You must install the interface module before you can configure its interfaces in the Firebox.
What other OCP cards are available for these appliances?
WatchGuard also offers a 4-port 25G SFP28 OCP 3.0 card for the same models.
