UACC-OM-SM-10G-S-2 Ubiquiti UFiber BiDi Single-Mode 10G Module 2-Pack

$330.98 AUD

20+ in stockShips from the warehouse closest to you

BrisbaneSydneyMelbourneAdelaidePerthNorth Lakes

Pickup may be possible in Sydney, Brisbane, Melbourne, Adelaide and Perth

We ship from partner warehouses, so pickup is not automatic. Choose delivery at checkout and contact us if you would like to arrange pickup.

Description

Ubiquiti UFiber Single-Mode Module 10G BiDirectional 2-pack - Same 10Gbps speed, Less Cable Required. Only requires a single strand of fiber cable to operate, but still provides a full 10Gbps speed.

The 10 Gbps Bidirectional Single-mode Optical Module is a simplex transceiver that delivers up to 10 Gbps speed over distances up to 10 kilometers.

1x Fiber Patch Lead can now be used for 2x separate links thanks to BiDi

Features:

Supported Media: Single-Mode Fiber
Connector Type: 1x LC
BiDi: Yes
TX Wavelength: 1270 nm Blue 1330 nm Red
RX Wavelength: 1330 nm Blue 1270 nm Red
Data Rate: 10 Gbps SFP+
Cable Distance: 10 km

Frequently asked questions4 questions

What is the UACC-OM-SM-10G-S-2 and how many modules come in the pack?

It is a Ubiquiti UFiber BiDi single-mode 10G SFP+ module supplied as a 2-pack. Each module is a simplex transceiver that delivers up to 10 Gbps.

How many fibre strands does it need?

Because it is bidirectional (BiDi), it needs only a single strand of fibre to deliver a full 10 Gbps. One fibre patch lead can therefore carry two separate links, so less cable is required.

What distance does it support, and on what type of fibre?

It supports distances of up to 10 km over single-mode fibre. The connector type is a single LC.

What are the transmit and receive wavelengths?

One module transmits at 1270 nm and receives at 1330 nm (blue), while the other transmits at 1330 nm and receives at 1270 nm (red). The two modules operate as a matched pair, one at each end of the link.

Click HERE to access the Datasheet

Specifications11 specifications · 1 sections

Overview
Form Factor	SFP+
Connector	Simplex LC UPC
Supported Media	Single-Mode Fiber
TX Wavelength	1270 / 1330 nm
RX Wavelength	1330 / 1270 nm
Supported Data Rate	1 / 10 Gbps
Supported Cable Distance	10 km (6.2 mi)
Max. Power Consumption	1 W
Pack Options	2-Pack / 20-Pack
Ambient Operating Temperature	0 to 70° C (32 to 158° F)
WARNING	CLASS 1 LASER PRODUCT, IEC/EN 60825-1:2014 / Do not look into the ends of the fiber optic cable or SFP module while converters are powered.
