LTU-Pro Ubiquiti LTU Pro 5GHz Antenna

Price:

$301.50

SKU: LTU-PRO


Chat 7am to 10pm - 7 days a week

We love what we do!

Shipping Costs From

Standard - $15 or Express - $20

Want The Best Prices?

Request a quote


5 GHz PtMP LTU Client with advanced RF performance, functions in a PtMP environment with the LTU-Rocket as the BaseStation.



Incorporating innovative industrial design with advanced technology, the LTU Pro is a Point-to-MultiPoint (PtMP) 5 GHz high-performance subscriber station. Based on Ubiquiti's proprietary LTU technology, the LTU Pro is not impeded by the limitations of standard 802.11 Wi-Fi technology.



It features an integrated high-gain dish for long range and high performance. Channel width flexibility (10/20/30/40/50 MHz) allows independent TX and RX channel frequency configurations anywhere within the radio band to avoid local interference.



Features:


PtMP CPE
1024 QAM
10/20/30/40/50 MHz channel bandwidth
Central configuration management from AP side
Frequency split
Automatic power adjustments
Router mode support


Functions in a PtMP environment with the LTU-Rocket as the basestation

  • Datasheets and Guides

Click HERE to access the Datasheet

Click HERE to access the Installation Guide


Learn how to create the perfect Point to Point connection

Step One - Get to know how a point to point works


Step Two - Choose your Point to Point device

There are many factors that affect a point to point to point connection, including distance, elevation, obstructions etc.   Please do reach out to our team if you are not sure.  We have listed some of the most common devices below, which should be good for connections that are generally less than 2km in length.

Step Three - You will probably need some way to mount it


Step Four - You will need to power it

Many of the devices will come with a PoE injector in the box.  If they don't you will need to either power it from a PoE switch or a PoE injector.


Not sure what PoE is, this video may help.
