SonicWall SonicWave 681 Access Point

Price:

$2,812.32

SKU: 03-SSC-0462

If you can't find the item you are after in stock, please chat to us.  Supply chain issues mean these are often ordered directly from SonicWall for each customer with a lead time of around 14 days.


Chat 7am to 10pm - 7 days

We love what we do!

Shipping Costs From

Standard - $15 or Express - $20

Want The Best Prices?

Request a quote


Powered by Wi-Fi 6 technology, the new SonicWave 600 series wireless access points, coupled with Wireless Network Manager, enable organizations to automatically secure wireless traffic while boosting performance and simplifying connectivity.



SonicWall SonicWave series wireless access points (APs) combine high-performance IEEE 802.11ac Wave 2 wireless technology with flexible deployment options. These APs can be managed via the cloud using SonicWall WiFi Cloud Manager (WCM) or through SonicWall’s industry-leading next-generation firewalls. The result is a solution that could be untethered from the firewall to provide a superior experience for WiFi users that’s as secure as any wired connection.



SonicWall SonicWave 600 series Access Points (APs) work together with SonicWall firewalls to deliver exceptional wireless speed, while securing your network and data against encrypted attacks.



Performance
SonicWall’s SonicWave 600 Series Access Points utilize 802.11ax technology, improving performance in complex environments. The use of 1024 QAM allows more data to pass through, and 802.11ax provides enhancements in MU-MIMO, with both uplink and downlink capabilities. Additionally, 802.11ax works in both the 2.4 GHz and 5 GHz bands. Testing has shown that 802.11ax can reduce latency by 75% and enable up to a 4X improvement in overall throughput, with nominal data rate improvement of up to 37% compared to 802.11ac Wave 2.



Enhanced user experience
SonicWave APs enhance the user experience in a number of ways. Not only are processor speeds faster, but beamforming allows for a more direct connection that is faster and more reliable than without beamforming. Improved power control methods help to avoid interference with nearby networks, making for a better experience. And Target Wake Time management helps preserve battery life in mobile devices.



Best-in-class wireless security
Most SonicWave access points include a separate radio dedicated to security, which performs rogue AP detection, passive scanning and packet capturing. The SonicWave solution also integrates additional security-related features, including wireless intrusion detection and prevention, virtual AP segmentation, wireless guest services, RF monitoring and wireless packet capture. SonicWave APs also feature zero-wait DFS, which identifies and avoids interference with radar systems while eliminating the wait associated with being booted from one DFS channel and finding another to connect with.



Intuitive cloud management and monitoring tool
SonicWave APs are easy to set up and deploy. They integrate with SonicWall Wireless Network Manager, which is a highly intuitive, scalable and centralized Wi-Fi network management system capable of delivering rich wireless and switching analytics, as well as simplified, single-paneof-glass onboarding via the cloud. The APs also integrate with WiFi Planner, a site survey tool that enables you to optimally design and deploy a wireless network, resulting in a reduced total cost of ownership. And with RF spectrum analysis, you can detect and identify the source of RF interference and monitor the health of a wireless system.



Zero-Touch Deployment
Zero-Touch makes it easy to register your unit and onboard SonicWave APs with the help of the SonicWall SonicExpress mobile app. The APs are automatically detected and provisioned with Zero-Touch Deployment. Available on iOS and Android, the SonicExpress mobile app lets network administrators monitor and manage networks from anywhere.

  • Datasheets and Guides

Click HERE to access the Datasheet

Click HERE to access the Installation Guide


subscriptions & accessories

SonicWall Parts & Accessories

SonicWave 641

SonicWave 681

SonicWave 432o

SonicWall SonicWave 641  Indoor Point
SonicWall SonicWave 681  Indoor Point
SonicWall SonicWave 432o Outdoor Access Point

  • Which Model?
  • More protection?
  • Thinking  firewall?

SonicWave Wireless Access Points from SonicWall provide your business with an enhanced user experience by delivering the performance, range and reliability of 802.11ac Wave 2 and 802.11ax technologies. Benefit from advanced, industry-leading security and wireless features. Leverage ease of deployment and management at a low total cost of ownership.


SonicWave 641

SonicWave 681

SonicWave 432o

Radios & Streams

Wi-Fi 6 4x4
Dedicated 3rd scanning Radio

Wi-Fi 6 4x4 (2.4Ghz)
Wi-Fi 6 8x8 (5Ghz)
Dedicated 3rd scanning Radio

Outdoor

Wi-Fi 5 4x4
Dedicated 3rd scanning Radio

Number Of Antennas

8 Internal

12 Internal

8 External N-Type Connectors

Maximum Data Rate

4800 Mbps (5 Ghz)
1147 Mbps (2.4 Ghz)

4800 Mbps (5 Ghz)
1147 Mbps (2.4 Ghz)

1733 Mbps (5 Ghz)
574 Mbps (2.4 Ghz)

Ports

1 x 2.5 GbE (PoE+)

1 x 5 GbE (PoE+)

1 x 1 GbpE (PoE+)
1 x 2.5 GbE

Power Consumption

23W

34W


21.2W

Mounting Option (Included)

Ceiling Mounting Kit

Ceiling Mounting Kit

Pole Mounting Kit

Mounting Options (Sold Separately)

Universal Standing Bracket (WG9017)

Universal Standing Bracket (WG9017)

N/A

Max Connected Clients (Per Radio)

256

256

128

Max SSIDs

8

8

8

Our Serving suggestion

Environment

Medium Density / Retail / Schools / Offices

Medium Density / Retail / Schools / Offices

High Density Outdoors / Manufacturing

Sonicwall SEcure wireless videos

SonicWave 600 Series Access Points

Ideal in complex multi-device situations, the 600 Series boosts wireless performance with the power of ultra-high-speed Wi-Fi 6.


With this series, you gain ‘always-on, always-secure’ access point operations across complex enterprise environments while simplifying the user experience.


All SonicWave access points are integrated with the cloud-delivered Wireless Network Manager (WNM).

SonicWall Wireless Network Manager

Leverage the ultimate flexibility and reliability of the cloud. SonicWall Wireless Network Manager (WNM) is a highly intuitive, scalable and centralized wireless and switching network management system. It unifies multiple tenants, locations and zones, providing integrated management for thousands of SonicWave access points and SonicWall Switches.


From a single pane of glass, WNM is capable of delivering rich analytics, powerful features and simplified onboarding via the cloud. This cloud-based infrastructure simplifies access, control and troubleshooting capabilities for organizations of any size. Wireless Network Manager can be deployed and accessed across multiple regions from anywhere with an Internet connection, all without the cost of complex overlay management systems.
